Transistor

* General Transistor *


	General Transistor	pin type	mark	piece	BOX	Vce	mA	mW	fc	R
PNP	2SA1037K		FQ			50	100	200	140㎒
PNP	2SA1162Y		SY			60	150	150	150㎒
PNP	KTA1298		IY			30	800	200	-
PNP	KTA1504S		ASY			50	150	150	80㎒
PNP	KTA1505S		AZY			30	500	150	200㎒
PNP	DTA114YK		54			50	100		R1/R2	10k/47k
PNP	KSR2102-MTF		R52			50	100		R1/R2	10k/10k
NPN	2SC2412K		BR			50	100	200	180㎒
NPN	STC2412Y		DAY			50	100	200	180㎒
NPN	STC2712		LY			60	150	150	150㎒
NPN	KTC3199S		ADG			120	100	150	100㎒
NPN	KTC3875S		ALY			50	150	150	80㎒
NPN	KTC3876S		WY			30	500	150	300㎒
NPN	2SC3859-TA		PY				100		Rb	10k
NPN	KRC106S		NF			50	100	200	R1/R2	4.7/47k
NPN	RN1406		XF			50	100	200	R1/R2	4.7/47k
PNP	KTA1663	SOT-89	HY			30	1.5	1	120㎒
PNP	2SB798		DL	ppjj	%	30	1	2	0㎒
PNP	2SB1188		BC	fppj		30	1.5	1	0㎒
NPN	KTC4375Y	SOT-89	GY			30	1.5	1	120㎒
NPN	KTC4377D	SOT-89	SD			20	3	1	150㎒
PNP	A1267	TO92M				50	150	400	80㎒	*
NPN	KTC3199	TO92M				50	150	400	80㎒	*
NPN	KTC3198	TO92				50	150	625	80㎒
NPN	KTC3202	TO92				30	500	625	300㎒
NPN	KTC3204	TO92M				30	800	400	120㎒
NPN	?KTC3120/1959					30	500		300㎒
	3120
PNP	A561
PNP	A562
	A11

* RF Transistor *


* Power(RF) Transistor *


* FET *


                                                                                              KMA2D3P20S       KMA2D4P20SA       -2.3A / -2.4A   0.130Ω
